Needle Roller Bearing NA4907 2RS

Name: Needle Roller Bearing NA4907 2RS
SKU: NA4907-2RS-MTM

Availability: Available

product code: NA4907-2RS-MTM

product ean: 5907772125700

d [mm]	35
D [mm]	55
B [mm]	20
Fw [mm]	42
rsmin [mm]	0,6
load rating dynam. [N]	31900
load rating stat. [N]	54000
Weight [kg]	0,170

Download as PDF

Pillow Block Bearing UCT212

UCT212-MTM

d [mm] - 60

o [mm] - 32

g [mm] - 19

p [mm] - 102

q [mm] - 64

S [mm] - 35

b [mm] - 102

k [mm] - 22

e [mm] - 130

a [mm] - 146

W [mm] - 194

j [mm] - 64

l [mm] - 42

h [mm] - 119

Bi [mm] - 65,1

n [mm] - 25,4

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Rod End SA25 T/K

SA25-T/K-MTM

D [mm] - 25

B [mm] - 31

M [mm] - 22

A [mm] - 60

F [mm] - 94

L [mm] - 124

O [mm] - 29,6

G [mm] - M24 x 2,00

GL [mm] - 58

Weight [kg] - 0,640

load rating dynam. [N] - 69000

load rating stat. [N] - 85000

Available

Product prices will become visible after signing in.

Insert ball bearing K6205 2RS

K6205-2RS-MTM

d [mm] - 25

D [mm] - 52

Be [mm] - 15

load rating dynam. [N] - 10780

load rating stat. [N] - 6980

Weight [kg] - 0,120

Available

Product prices will become visible after signing in.

Spherical roller bearings 29412 M

29412-M-MTM

d [mm] - 60

D [mm] - 130

B [mm] - 42

nośność dynam. [N] - 290000

nośność stat. [N] - 925000

Waga [kg] - 2,80

Available

Product prices will become visible after signing in.

Ball Bearing 6403 2RS

6403-2RS-MTM

d [mm] - 17

D [mm] - 62

B [mm] - 17

load rating dynam. [N] - 22900

load rating stat. [N] - 10800

Weight [kg] - 0,272

Available

Product prices will become visible after signing in.

Insert ball bearing SA208

SA208-MTM

d [mm] - 40

D [mm] - 80

Be [mm] - 18

n [mm] - 9,5

Bi [mm] - 41

b0 [mm] - 27

b3 [mm] - 18

W [mm] - 60

ds [mm] - M8 x 1,00

load rating dynam. [N] - 22800

load rating stat. [N] - 15800

Weight [kg] - 0,67

Available

Product prices will become visible after signing in.

Needle Roller Bearing NA4906 2RS

NA4906-2RS-MTM

d [mm] - 30

D [mm] - 47

B [mm] - 17

Fw [mm] - 35

rsmin [mm] - 0,3

load rating dynam. [N] - 25500

load rating stat. [N] - 39000

Weight [kg] - 0,100

Available

Product prices will become visible after signing in.

Insert ball bearing K6206 2RS

K6206-2RS-MTM

d [mm] - 30

D [mm] - 62

Be [mm] - 16

nośność dynam. [N] - 14970

nośność stat. [N] - 10040

Waga [kg] - 0,185

Available

Product prices will become visible after signing in.

Insert ball bearing K6209 2RS

K6209-2RS-MTM

d [mm] - 45

D [mm] - 85

Be [mm] - 19

load rating dynam. [N] - 24360

load rating stat. [N] - 17710

Weight [kg] - 0,395

Available

Product prices will become visible after signing in.

Insert ball bearing K6210 2RS

K6210-2RS-MTM

d [mm] - 50

D [mm] - 90

Be [mm] - 20

load rating dynam. [N] - 26980

load rating stat. [N] - 19840

Weight [kg] - 0,450

Available

Product prices will become visible after signing in.

Ball Bearing 62/28 2RSC3

62/28-2RSC3-MTM

d [mm] - 28

D [mm] - 58

B [mm] - 16

nośność dynam. [N] - 19800

nośność stat. [N] - 9750

Waga [kg] - 0,175

Available

Product prices will become visible after signing in.

Needle Roller Bearing NA4901 2RS

NA4901-2RS-MTM

d [mm] - 12

D [mm] - 24

B [mm] - 13

Fw [mm] - 16

rsmin [mm] - 0,3

load rating dynam. [N] - 9900

load rating stat. [N] - 12200

Weight [kg] - 0,026

Available

Product prices will become visible after signing in.
