Lubricated high vacuum pumps DB 2D

DB 2D

Nominal capacity [m3/h] - 2,4

Pneurop capacity [m3/h] - 2

Total final pressure [mbar-hPa] - 0,005

Partial final pressure [ mbar [ micron] ] - 0,0005 [0,37]

Total final pressure with gas ballast [mbar-hPa] - 0,2

Max intel pressure for water vapour [mbar-hPa] - 15

Max water vapour pumping rate [kg/h] - 0,02

Motor power [KW] 1~/3~) - (0,25/-)

Nominal r.p.m [n/min] - 2800

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - (10 [98,1])

Oil quantity [min- max dm3] - 0,26 ÷ 0,37

Pump intake / outlet [DN] - DN16 / 1/2”G

Operating temperature [°C] - 45 ÷ 50

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps DC 16D

DC 16D

Nominal capacity [m3/h] - 17

Pneurop capacity [m3/h] - 16

Total final pressure [mbar-hPa] - 0,005

Partial final pressure [ mbar [ micron] ] - 0,0005 [0,37]

Total final pressure with gas ballast [mbar-hPa] - 0,08

Max intel pressure for water vapour [mbar-hPa] - 17

Max water vapour pumping rate [kg/h] - 0,22

Motor power [KW] 1~/3~) - 0,75 / 0,55

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - 25,5 [250,1] / 22,5 [220,7]

Oil quantity [min- max dm3] - 0,62 ÷ 0,80

Pump intake / outlet [DN] - DN25 / 1/2”G

Operating temperature [°C] - 60 ÷ 65

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps DC 16DEX

DC 16DEX

Nominal capacity [m3/h] - 17

Pneurop capacity [m3/h] - 16

Total final pressure [mbar-hPa] - 0,005

Partial final pressure [ mbar [ micron] ] - 0,0005 [0,37]

Total final pressure with gas ballast [mbar-hPa] - 0,08

Max intel pressure for water vapour [mbar-hPa] - 17

Max water vapour pumping rate [kg/h] - 0,22

Motor power [KW] 1~/3~) - 0,75 / 0,55

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - 25,5 / 22,5

Oil quantity [min- max dm3] - 0,62 ÷ 0,80

Pump intake / outlet [DN] - DN25 / DN25

Operating temperature [°C] - 60 ÷ 65

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps DC 4D

DC 4D

Nominal capacity [m3/h] - 6,5

Pneurop capacity [m3/h] - 5,6

Total final pressure [mbar-hPa] - 0,005

Partial final pressure [ mbar [ micron] ] - 0,0005 [0,37]

Total final pressure with gas ballast [mbar-hPa] - 0,3

Max intel pressure for water vapour [mbar-hPa] - 37

Max water vapour pumping rate [kg/h] - 0,15

Motor power [KW] 1~/3~) - 0,75 / 0,55

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - 22,5 [220,7] / 19,5 [191,2]

Oil quantity [min- max dm3] - 0,53 ÷ 0,70

Pump intake / outlet [DN] - DN25 / 1/2”G

Operating temperature [°C] - 55 ÷ 60

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps DC 8D

DC 8D

Nominal capacity [m3/h] - 9

Pneurop capacity [m3/h] - 8,2

Total final pressure [mbar-hPa] - 0,005

Partial final pressure [ mbar [ micron] ] - 0,0005 [0,37]

Total final pressure with gas ballast [mbar-hPa] - 0,2

Max intel pressure for water vapour [mbar-hPa] - 25

Max water vapour pumping rate [kg/h] - 0,15

Motor power [KW] 1~/3~) - 0,75 / 0,55

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - 23,5 [230,5] / 20,5 [201,1]

Oil quantity [min- max dm3] - 0,75 ÷ 1,00

Pump intake / outlet [DN] - DN25 / 1/2”G

Operating temperature [°C] - 55 ÷ 60

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps RC 4D

RC 4D

Nominal capacity [m3/h] - 4,3

Pneurop capacity [m3/h] - 4

Total final pressure [mbar-hPa] - 0,01

Partial final pressure [ mbar [ micron] ] - 0,005 [3,7]

Total final pressure with gas ballast [mbar-hPa] - 0,2

Max intel pressure for water vapour [mbar-hPa] - 20

Max water vapour pumping rate [kg/h] - 0,05

Motor power [KW] 1~/3~) - 0,37 / 0,37

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - 12 [117,7] / 10 [98,1]

Oil quantity [min- max dm3] - 0,45

Pump intake / outlet [DN] - 1/4”G / 1/2”G

Operating temperature [°C] - 50 ÷ 55

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps RC 4M

RC 4M

Nominal capacity [m3/h] - 4,3

Pneurop capacity [m3/h] - 4

Total final pressure [mbar-hPa] - 0,1

Partial final pressure [ mbar [ micron] ] - 0,05 [37]

Total final pressure with gas ballast [mbar-hPa] - 3

Max intel pressure for water vapour [mbar-hPa] - 40

Max water vapour pumping rate [kg/h] - 0,1

Motor power [KW] 1~/3~) - 0,37 / 0,37

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - 11 [107,9] / 9 [88,2]

Oil quantity [min- max dm3] - 0,45

Pump intake / outlet [DN] - 1/4”G / 1/2”G

Operating temperature [°C] - 50 ÷ 55

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps RC 50M

RC 50M

Nominal capacity [m3/h] - 50

Pneurop capacity [m3/h] - - - -

Total final pressure [mbar-hPa] - 0,05

Partial final pressure [ mbar [ micron] ] - - - -

Total final pressure with gas ballast [mbar-hPa] - 0,2

Max intel pressure for water vapour [mbar-hPa] - 8

Max water vapour pumping rate [kg/h] - 0,4

Motor power [KW] 1~/3~) - 1,1

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 63

Weight [Kg[N]] (1~/3~) - 33,5 [328,6]

Oil quantity [min- max dm3] - 0,7 ÷ 1,00

Pump intake / outlet [DN] - DN40 / 1/2”G

Operating temperature [°C] - 55 ÷ 60

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps RC 8D

RC 8D

Nominal capacity [m3/h] - 8,5

Pneurop capacity [m3/h] - 8

Total final pressure [mbar-hPa] - 0,01

Partial final pressure [ mbar [ micron] ] - 0,005 [3,7]

Total final pressure with gas ballast [mbar-hPa] - 0,2

Max intel pressure for water vapour [mbar-hPa] - 20

Max water vapour pumping rate [kg/h] - 0,09

Motor power [KW] 1~/3~) - 0,37 / 0,37

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - 13,2 [129,4] / 11,2 [109,8]

Oil quantity [min- max dm3] - 0,35

Pump intake / outlet [DN] - 1/4”G / 1/2”G

Operating temperature [°C] - 50 ÷ 55

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps RC 8M

RC 8M

Nominal capacity [m3/h] - 8,5

Pneurop capacity [m3/h] - 8

Total final pressure [mbar-hPa] - 0,1

Partial final pressure [ mbar [ micron] ] - 0,05 [37]

Total final pressure with gas ballast [mbar-hPa] - 3

Max intel pressure for water vapour [mbar-hPa] - 40

Max water vapour pumping rate [kg/h] - 0,18

Motor power [KW] 1~/3~) - 0,37 / 0,37

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - 12 [117,7] / 10 [98,1]

Oil quantity [min- max dm3] - 0,45

Pump intake / outlet [DN] - 1/4”G / 1/2”G

Operating temperature [°C] - 50 ÷ 55

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated high vacuum pumps RD 2D

RD 2D

Nominal capacity [m3/h] - 2

Pneurop capacity [m3/h] - 1,8

Total final pressure [mbar-hPa] - ≤ 0,5

Partial final pressure [ mbar [ micron] ] - 0,1 [74]

Total final pressure with gas ballast [mbar-hPa] - - - -

Max intel pressure for water vapour [mbar-hPa] - - - -

Max water vapour pumping rate [kg/h] - - - -

Motor power [KW] 1~/3~) - (0,12/ -)

Nominal r.p.m [n/min] - 2800

Noise level pump [Db (A)] - 52

Weight [Kg[N]] (1~/3~) - (5 [49] / -)

Oil quantity [min- max dm3] - 0,15

Pump intake / outlet [DN] - 1/4”G / 1/2”G

Operating temperature [°C] - 45 ÷ 50

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated pump systems XC 405

XC 405

Nominal capacity [m3/h] - 410

Total final pressure [mbar-hPa] - 0,1

Max intel pressure for water vapour [mbar-hPa] - 25

Max water vapour pumping rate [kg/h] - 7

Motor power [KW] 1~/3~) - 2x 5,5

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 73

Weight [Kg[N]] (1~/3~) - (-/ 450)

Oil quantity [min- max dm3] - 8 ÷ 10

Pump intake / outlet - 2-1/2

continuous duty working range [mbar-hPa] - 400 ÷ 0,5

Operating temperature [°C] - 70÷75

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated pump systems XC 605

XC 605

Nominal capacity [m3/h] - 610

Total final pressure [mbar-hPa] - 0,1

Max intel pressure for water vapour [mbar-hPa] - 25

Max water vapour pumping rate [kg/h] - 10

Motor power [KW] 1~/3~) - (-/ 2x7,5)

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 74

Weight [Kg[N]] (1~/3~) - (-/ 470)

Oil quantity [min- max dm3] - 8 ÷ 10

Pump intake / outlet - 2-1/2

continuous duty working range [mbar-hPa] - 400 ÷ 0,5

Operating temperature [°C] - 75 ÷ 80

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated pump systems XC 905

XC 905

Nominal capacity [m3/h] - 915

Total final pressure [mbar-hPa] - 0,1

Max intel pressure for water vapour [mbar-hPa] - 25

Max water vapour pumping rate [kg/h] - 15

Motor power [KW] 1~/3~) - (-/ 3x7,5)

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 76

Weight [Kg[N]] (1~/3~) - 740

Oil quantity [min- max dm3] - 12 ÷ 15

Pump intake / outlet - 4

continuous duty working range [mbar-hPa] - 400 ÷ 0,5

Operating temperature [°C] - 75 ÷ 80

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 106

LC 106

Nominal capacity [m3/h] - 106

Total final pressure with gas ballast closed [mbar-hPa] - 0,1

Max intel pressure for water vapour [mbar-hPa] - 11

Max water vapour pumping rate [kg/h] - 1

Motor power [KW] 1~/3~) - 2,2

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 66

Weight [Kg[N]] (1~/3~) - 70 [691,6]

Oil quantity [min- max dm3] - 2 ÷ 3

Pump intake / outlet - 1-1/2”G / 1-1/4”G

continuous duty working range [mbar-hPa] - 400 ÷ 0,1

Operating temperature [°C] - 75 ÷ 80

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 106 KZERO

LC 106 KZERO

Nominal capacity [m3/h] - 106

Total final pressure with gas ballast closed [mbar-hPa] - 4

Max intel pressure for water vapour [mbar-hPa] - 11

Max water vapour pumping rate [kg/h] - 1

Motor power [KW] 1~/3~) - (-/2,2)

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 67

Weight [Kg[N]] (1~/3~) - (-/0,5 [691,6])

Oil quantity [min- max dm3] - 2 ÷ 3

Pump intake / outlet - 1-1/2”G / 1-1/4”G

continuous duty working range [mbar-hPa] - 400 ÷ 4

Operating temperature [°C] - 95 ÷ 100

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 106WR

LC 106WR

Nominal capacity [m3/h] - 106

Total final pressure [mbar-hPa] - 4

Max intel pressure for water vapour [mbar-hPa] - 40

Max water vapour pumping rate [kg/h] - 3,2

Motor power [KW] 1~/3~) - (-/2,2)

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 66

Weight [Kg[N]] (1~/3~) - (-/71 [696,5])

Oil quantity [min- max dm3] - 2 ÷ 3

Pump intake / outlet - 1-1/2″G / 1-1/4”G

continuous duty working range [mbar-hPa] - 400 ÷ 4

Operating temperature [°C] - 80 ÷ 85

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 12

LC 12

Nominal capacity [m3/h] - 12

Total final pressure [mbar-hPa] - 2

Max intel pressure for water vapour [mbar-hPa] - 35

Max water vapour pumping rate [kg/h] - 0,30

Motor power [KW] 1~/3~) - 0,45/ 0,37

Nominal r.p.m [n/min] - 2800

Noise level pump [Db (A)] - 62

Weight [Kg[N]] (1~/3~) - 14 [137,3]/ 12,5 [122,6]

Oil quantity [min- max dm3] - 0,30 ÷ 0,40

Pump intake / outlet - 1/2″G / 1/2″G

continuous duty working range [mbar-hPa] - 400 ÷ 4

Operating temperature [°C] - 60 ÷ 65

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 12WR

LC 12WR

Nominal capacity [m3/h] - 12

Total final pressure [mbar-hPa] - 50

Max intel pressure for water vapour [mbar-hPa] - 35

Max water vapour pumping rate [kg/h] - 0,30

Motor power [KW] 1~/3~) - 0,45 / 0,37

Nominal r.p.m [n/min] - 2800

Noise level pump [Db (A)] - 62

Weight [Kg[N]] (1~/3~) - 17,5 [171,7] / 15 [147,1]

Oil quantity [min- max dm3] - 0,30 ÷ 0,40

Pump intake / outlet - 1-1/2″G / 1-1/4”G

continuous duty working range [mbar-hPa] - 400 ÷ 50

Operating temperature [°C] - 60 ÷ 65

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 151

LC 151

Nominal capacity [m3/h] - 151

Total final pressure with gas ballast closed [mbar-hPa] - 0,1

Max intel pressure for water vapour [mbar-hPa] - 11

Max water vapour pumping rate [kg/h] - 1,4

Motor power [KW] 1~/3~) - 3,3

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 68

Weight [Kg[N]] (1~/3~) - 80 [784,8]

Oil quantity [min- max dm3] - 2 ÷ 3

Pump intake / outlet - 1-1/2”G / 1-1/4”G

continuous duty working range [mbar-hPa] - 400 ÷ 0,1

Operating temperature [°C] - 75 ÷ 80

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 151 KZERO

LC 151 KZERO

Nominal capacity [m3/h] - 151

Total final pressure with gas ballast closed [mbar-hPa] - 4

Max intel pressure for water vapour [mbar-hPa] - 11

Max water vapour pumping rate [kg/h] - 1,4

Motor power [KW] 1~/3~) - (-/3,3)

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 69

Weight [Kg[N]] (1~/3~) - (-/80 [784,8)

Oil quantity [min- max dm3] - 2 ÷ 3

Pump intake / outlet - 1-1/2”G / 1-1/4”G

continuous duty working range [mbar-hPa] - 400 ÷ 4

Operating temperature [°C] - 100 ÷ 105

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 151WR

LC 151WR

Nominal capacity [m3/h] - 151

Total final pressure [mbar-hPa] - 4

Max intel pressure for water vapour [mbar-hPa] - 50

Max water vapour pumping rate [kg/h] - 5

Motor power [KW] 1~/3~) - 3,3

Nominal r.p.m [n/min] - 1400

Noise level pump [Db (A)] - 68

Weight [Kg[N]] (1~/3~) - 80,5 [784,8]

Oil quantity [min- max dm3] - 2 ÷ 3

Pump intake / outlet - 1-1/2″G / 1-1/4”G

continuous duty working range [mbar-hPa] - 400 ÷ 4

Operating temperature [°C] - 85 ÷ 90

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 2

LC 2

Nominal capacity [m3/h] - 2

Total final pressure [mbar-hPa] - 10

Motor power [KW] 1~/3~) - 0,12 / 0,12

Nominal r.p.m [n/min] - 2800

Noise level pump [Db (A)] - 48

Weight [Kg[N]] (1~/3~) - 5,4 [48,6] / 5,4 [48,6]

Oil quantity [dm3] - 0,065

Pump intake / outlet - Ø9mm (1/8″G) / - - -

continuous duty working range [mbar-hPa] - 500 ÷ 10

Operating temperature [°C] - 50 ÷ 55

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m s.l.m.

On order

Product prices will become visible after signing in.

Lubricated rotary vane vacuum pumps LC 20

LC 20

Nominal capacity [m3/h] - 20

Total final pressure [mbar-hPa] - 2

Max intel pressure for water vapour [mbar-hPa] - 15

Max water vapour pumping rate [kg/h] - 0,25

Motor power [KW] 1~/3~) - 0,75/ 0,75

Nominal r.p.m [n/min] - 2800

Noise level pump [Db (A)] - 64

Weight [Kg[N]] (1~/3~) - 19 [186,4] / 17 [166,8]

Oil quantity [min- max dm3] - 0,45 ÷ 0,50

Pump intake / outlet - 1/2"G / 1/2"G

continuous duty working range [mbar-hPa] - 400 ÷ 2

Operating temperature [°C] - 60 ÷ 65

Required room temp. for place of installation [°C] - 12 ÷ 40

max humidity/ altitude - 80% / 1000m n.p.m

On order

Product prices will become visible after signing in.
