Tapered Roller Bearing 30210

Name: Tapered Roller Bearing 30210
SKU: 30210-MTM

Availability: Available

product code: 30210-MTM

product ean: 5907772105146

d [mm]	50
D [mm]	90
T [mm]	21,75
Waga [kg]	0,540
nośność dynam. [N]	76500
nośność stat.[N]	91500

Download as PDF

Deep groove ball bearing 6010 2RS

6010-2RS-MTM

d [mm] - 50

D [mm] - 80

B [mm] - 16

nośność dynam. [N] - 21600

nośność stat. [N] - 16000

Waga [kg] - 0,261

On order

Product prices will become visible after signing in.

Lock nut KM09

KM09-MTM

d [mm] - 56

D [mm] - 65

B [mm] - 10

G [mm] - M45 x 1,50

m [mm] - 6

n [mm] - 2,5

Weight [kg] - 0,110

Washer model - MB09

Available

Product prices will become visible after signing in.

Retaining ring SEGW47(100pcs)

SEGW47(100szt)-MTM

d1 [mm] - 47

d2 [mm] - 49,5

d3 [mm] - 50,5

d5 min [mm] - 2,5

amax [mm] - 6,4

~b [mm] - 4,4

s +/- 4% [mm] - 1,7

m H13 [mm] - 1,85

n min [mm] - 3,8

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCP210

UCP210-MTM

d [mm] - 50

h [mm] - 57,2

a [mm] - 206

e [mm] - 159

b [mm] - 60

S1 [mm] - 20

S2 [mm] - 23

g [mm] - 21

W [mm] - 113

Bi [mm] - 51,6

n [mm] - 19

Bolt - M16

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Spherical plain bearing GE017 ES2RS

GE017-ES2RS-MTM

d [mm] - 17

D [mm] - 30

B [mm] - 14

C [mm] - 10

dk [mm] - 25

Weight [kg] - 0,040

load rating dynam. [N] - 21000

load rating stat. [N] - 106000

Available

Product prices will become visible after signing in.

Chain V16B-1

V16B-1-MTM

ISO DIN - 16B-1

Pitch P [inch] - 1"

Pitch P [mm] - 25.4

⌀ Roller d1 max [mm] - 15.88

Inner working dimension b1 min [mm] - 17.02

⌀ pin d2 max [mm] - 8.28

Pin lenght L max [mm] - 36.1

Connecting pin lenght Lc max [inch] - 41.5

Inner plate depth H max [mm] - 21.08

Breaking load rating Q min [KN] - 60

Waga [kg/m] - 2,71

Available

Product prices will become visible after signing in.

Spherical plain bearing GE030 ES

GE030-ES-MTM

d [mm] - 30

D [mm] - 47

B [mm] - 22

C [mm] - 18

dk [mm] - 40.7

Waga [kg] - 0.149

nośność dynam. [N] - 62000

nośność stat. [N] - 310000

Available

Product prices will become visible after signing in.

Linear rod with support PWD20-2000mm-MTM

Rod+PWD20-2000mm-MTM

⌀ Diameter - 20

H [mm] - 27

E [mm] - 22,5

W [mm] - 45

L [mm] - 2000

F [mm] - 17,7

T [mm] - 5

K [mm] - 10

J [mm] - 19

M [mm] - 8

B [mm] - 30

N [mm] - 20

P [mm] - 150

S1 [mm] - 5,5

Weight [kg] - 6,6

Waga [kg/m] - 3,30

Available

Product prices will become visible after signing in.

Lock nut KM11

KM11-MTM

d [mm] - 67

D [mm] - 75

B [mm] - 11

G [mm] - M55 x 2,00

m [mm] - 7

n [mm] - 3

Weight [kg] - 0,150

Washer model - MB11

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCFL205

UCFL205-MTM

d [mm] - 25

a [mm] - 130

e [mm] - 99

i [mm] - 16

g [mm] - 13

l [mm] - 27

S [mm] - 16

b [mm] - 68

z [mm] - 35,8

Bi [mm] - 34,1

n [mm] - 14,3

Bolt - M14

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Tapered Roller Bearing 30221

30221-MTM

d [mm] - 105

D [mm] - 190

T [mm] - 39

Weight [kg] - 4,250

load rating dynam. [N] - 270000

nośność stat.[N] - 355000

Available

Product prices will become visible after signing in.

Lock nut KM08

KM08-MTM

d [mm] - 50

D [mm] - 58

B [mm] - 9

G [mm] - M40 x 1,50

m [mm] - 6

n [mm] - 2,5

Weight [kg] - 0,078

Washer model - MB08

Available

Product prices will become visible after signing in.
