Pillow Block Bearing UCFL205

Name: Pillow Block Bearing UCFL205
SKU: UCFL205-MTM

Availability: Available

product code: UCFL205-MTM

product ean: 5907772142035

d [mm]	25
a [mm]	130
e [mm]	99
i [mm]	16
g [mm]	13
l [mm]	27
S [mm]	16
b [mm]	68
z [mm]	35,8
Bi [mm]	34,1
n [mm]	14,3
Bolt	M14
Note:	Version TS (with triple sealing) available on request

Download as PDF

Pillow Block Bearing UCFL206

UCFL206-MTM

d [mm] - 30

a [mm] - 148

e [mm] - 117

i [mm] - 18

g [mm] - 13

l [mm] - 31

S [mm] - 16

b [mm] - 80

z [mm] - 40,2

Bi [mm] - 38,1

n [mm] - 15,9

Bolt - M14

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCF208

UCF208-MTM

d [mm] - 40

a [mm] - 130

e [mm] - 102

i [mm] - 21

g [mm] - 16

l [mm] - 36

S [mm] - 16

Z [mm] - 51,2

Bi [mm] - 49,2

n [mm] - 19

Bolt - M14

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Lock washer MB06

MB06-MTM

d [mm] - 30

D1 [mm] - 38

D [mm] - 49

S [mm] - 1,25

E [mm] - 5

F [mm] - 27,5

B [mm] - 5

Weight [kg] - 0,00780

Available

Product prices will become visible after signing in.

Lock nut KM04

KM04-MTM

d [mm] - 26

D [mm] - 32

B [mm] - 6

G [mm] - M20 x 1,00

m [mm] - 4

n [mm] - 2

Weight [kg] - 0,020

Washer model - MB04

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCFL204

UCFL204-MTM

d [mm] - 17

a [mm] - 113

e [mm] - 90

i [mm] - 15

g [mm] - 11

l [mm] - 25,5

S [mm] - 12

b [mm] - 60

z [mm] - 33,3

Bi [mm] - 31

n [mm] - 12,7

Bolt - M10

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCP208

UCP208-MTM

d [mm] - 40

h [mm] - 49,2

a [mm] - 184

e [mm] - 137

b [mm] - 54

S1 [mm] - 17

S2 [mm] - 20

g [mm] - 18

W [mm] - 100

Bi [mm] - 49,2

n [mm] - 19

Bolt - M14

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCP204

UCP204-MTM

d [mm] - 20

h [mm] - 33,3

a [mm] - 127

e [mm] - 95

b [mm] - 38

S1 [mm] - 13

S2 [mm] - 19

g [mm] - 14

W [mm] - 62

Bi [mm] - 31

n [mm] - 12,7

Bolt - M10

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Ball Bearing 6002 ZZ

6002-ZZ-MTM

d [mm] - 15

D [mm] - 32

B [mm] - 9

load rating dynam. [N] - 5590

load rating stat. [N] - 2850

Weight [kg] - 0,030

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCF206

UCF206-MTM

d [mm] - 30

a [mm] - 108

e [mm] - 83

i [mm] - 18

g [mm] - 14

l [mm] - 31

S [mm] - 12

Z [mm] - 40,2

Bi [mm] - 38,1

n [mm] - 15,9

Bolt - M10

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Lock washer MB08

MB08-MTM

d [mm] - 40

D1 [mm] - 50

D [mm] - 62

S [mm] - 1,25

E [mm] - 6

F [mm] - 37,5

B [mm] - 6

Weight [kg] - 0,01230

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCP205

UCP205-MTM

d [mm] - 25

h [mm] - 36,5

a [mm] - 140

e [mm] - 105

b [mm] - 38

S1 [mm] - 13

S2 [mm] - 19

g [mm] - 15

W [mm] - 71

Bi [mm] - 34,1

n [mm] - 14,3

Bolt - M10

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.

Pillow Block Bearing UCF205

UCF205-MTM

d [mm] - 25

a [mm] - 95

e [mm] - 70

i [mm] - 16

g [mm] - 14

l [mm] - 27

S [mm] - 12

Z [mm] - 35,8

Bi [mm] - 34,1

n [mm] - 14,3

Bolt - M10

Note: - Version TS (with triple sealing) available on request

Available

Product prices will become visible after signing in.
